Service Call Tables
SM 4-73 D014/D015/D078/D079
Trouble-
shooting
SC822 C Self-diagnostic error 2: HDD *GW
3003
Check performed
when HDD is
installed:
HDD device busy for
over 31 s.
After a diagnostic
command is set for
Sthe HDD, but the
device remains busy
for over 6 s.
A diagnostic
command is issued
to the HDD device
but the result is an
erro
 HDD defective
 HDD harness
disconnected,
defective
 Controller board
defective
3004
No response
to the
self-diagnostic
command
from the ASIC
to the HDDs
 HDD
defective
3013
Mandolin
does not
respond, the
HDD device
remains
BUSY for
more than 31
s, or the
BUSY signal
does not drop
within 6 s after
 HDD
defective
 HDD
connecto
r loose or
defective
 Controller
defective
