Group 1000
D014/D015/D078/D079 5-14 SM
1111 Measure Mode
Nip Width Measurement Setting Mode
1 Nip Width:Execute
Determines whether the nip at the hot
roller and pressure roller is calibrated.
Touch [Execute].
2 Nip Width:Stop Time
Determines the down time of the
fusing/exit motor in the fusing nip band
calibration mode.
[1 to 100/1 sec.]
3 Nip Width:Stop Interval
Determines the intervals between the
down times of the fusing/exit motor in the
nip band calibration mode.
[0 to 2000/100 msec.]
4 Nip Width:Htg Roll Temp:Ctr
5 Nip Width:Htg Roll Temp:End
6 Nip Width:Press Roll Temp
11 Belt:0:off 1:on
12 Belt:Rotation Time
13 Belt:Htg Roll Temp:Ctr
14 Belt:Htg Roll Temp:End
15 Belt:Press Roll Temp
