Ricoh D014 - Page 568

Group 2000
D014/D015/D078/D079 5-26 SM
9 LEdge Custom:Bypass
10 LEdge Custom:LCT
11 LEdge: Tray 2
12 LEdge: Tray 3
13 LEdge: Tray 4
14 LEdge: Bypass
15 LEdge: LCT
16 LEdge: Duplex
2104 Skew Adj
Use these SPs to correct skew in color registration. For more, see "4.
Troubleshooting" in the B132/B200 Service Manual.
1 Bk-M
2 Bk-C
3 Bk-Y
11 Skew Corr Total M
12 Skew Corr Total C
13 Skew Corr Total Y
