Group 2000
SM 5-27 D014/D015/D078/D079
Service
Tables
2105
LD Syn PM Adj DFU
LD Pulse Modulation Synchronization Adjustment
Raises the pulse modulation for the LD0 beam of K.
1 Bk1
2 M1
3 C1
4 Y1
5 Bk2
6 M2
7 C2
8 Y2
2106 Poly Mtr OFF - Time Until Stop Polygon Motor Off Setting
The polygon mirror motor turns off if the machine receives no print job for the time
specified in this SP mode after the previous job was completed.
[0 to 180/1 sec]
2107 Prt Param On/Off
Switches enhanced shading on/off.
