Group 2000
D014/D015/D078/D079 5-28 SM
2108 Col Prt Stop
This SP determines which color to switch off for printing.
1 Bk
2 M
3 C
4 Y
[0 to 1/0]
0: Off. Color prints
1: On. Color does not print
2109 Test Pattern
Write Test Pattern. Some of these test patterns are used for copy image
adjustments but most are used primarily for design testing. These test patterns do
not use the IPU.
1 Image Add
Select "1" to have the patterns selected
with SP2109 002 print overlapped on one
another.
[0 to 1/1] 0: Off, 1: On
2 Select Pattern
Allows you to select the pattern to print.
[0 to 20/1]
0 Off
1 Grid Pattern
2 Slant Grid Pattern
3 2-Dot Horizontal Line
4 2-Dot Vertical Line
5 1-Dot Horizontal Line
6 1-Dot Vertical Line
