Group 2000
D014/D015/D078/D079 5-58 SM
2264 ID Sn Chk
ID Sensor Check: Touch [EXECUTE] to check the ID sensor.
2265 ID Sn Chk Disp
Displays the most recent ID sensor Vsg and Voffset readings.
Notes:
Vsg_reg is the reading of the direct sensors in the black and color ID sensors
that detect the reflectivity of the bare surface of ITB. If Vsg_reg is less than
3.8V, the ID sensor may be dirty, damaged, or disconnected
If Voffset_reg is less than 0.15, the ID sensor should be replaced. (The ID
sensors are replaced as a unit.)
1 Vsg_reg
3 Voffset_reg
