Group 2000
D014/D015/D078/D079 5-66 SM
2394
Margin FC:MH DFU
2395
Margin FC:HH DFU
2401 Norm K Bias
Sets the standard value of bias voltages at image transfer, and paper separation in
areas where black is used on plain paper during black-and-white printing.
1 ITB [0 to 70 / 0.1 ua]
7 Side1:PTR [-100 to 0/ 1 ua]
8 Side1:SepDC [0 to 10 / 0.1 ua]
9 Side1:SepAC [8 to 12 / 0.1 ua]
12 Side2:PTR [-100 to 0/ 0.1 ua]
13 Side2:SepDC [0 to 10/ 0.1 ua]
14 Side2:SepAC [8 to 12/ 0.1 ua]
2406 Norm FC Bias
Set Bias for Plain Paper: FC. Sets the standard value of bias voltages at image
transfer, and paper separation in areas the four colors are used on plain paper
during full color printing.
1 ITB:K
[0 to 70/0.1 μa]
2 ITB:M
[0 to 70/0.1 μa]
3 ITB:C
[0 to 70/0.1 μa]
4 ITM:Y
[-100 to 0/1 μa]
13 Side1:PTR
[-100 to 0/1 μa]
14 Side1:SepDC
[0 to 10/0.1 μa]
