Group 2000
SM 5-67 D014/D015/D078/D079
Service
Tables
15 Side1:SepAC
[8 to 12/0.1 μa]
21 Side1:PTR
[-100 to 0/1 μa]
22 Side1:SepDC
[0 to 10/0.1 μa]
23 Side1:SepAC
[8 to 12/1 μa]
2421 LEdge Cor:Norm K
Leading Edge Correction for Plain Paper: K. This SP sets the coefficient used to 1)
correct bias at the leading edge for black image transfer (ITB) 2) bias at image to
paper transfer, and 3) correct the dc and ac voltages applied at paper separation.
Notes: These settings apply:
To the distance from the leading edge set with SP2422
Only to black printing on plain paper at full speed (even when full-color is
selected).
7 Side1:PTR
8 Side1:SepDC
9 Side1:SepAC
12 Side2:PTR
13 Side2:SepDC
14 Side2:SepAC
[0 to 250/ 1%]
