Group 2000
D014/D015/D078/D079 5-72 SM
SP2443 – More than SP2304 003 Threshold 3, up to SP2304 004 Threshold 4
SP2444 – More than SP2304 004 Threshold 4, up to SP2305 005 Threshold 3
SP2445 – More than SP2304 005 Threshold 5
These settings apply 1) only where the image is created in full-color on plain paper
at full speed.
17 Side1:PTR
18 Side1:SepDC
19 Side1:SepAC
27 Side2:PTR
28 Side2:SepDC
29 Side2:SepAC
[10 to 200/ 1%]
2751 Sp1 K Bias
Set Bias for Special Paper 1: K. These SPs set the standard values of the electrical
charges that are applied to 1) create bias for image transfer from drum to ITB, 2)
create bias for image transfer from ITB to paper (PTR), and 3) neutralize the
charges on the both sides of the paper to separate the paper from the ITB (SepDC,
SepAC). These settings are used when printing on Special Paper 1 in the
black-and-white mode and are applied only to the image area.
1 ITB
[0 to 70/0.1 μa]
7 Side1:PTR
[-100 to 0/1 μa]
8 Side1:SepDC
[0 to 10/0.1 μa]
9 Side1:SepAC [8 to 12/0.1 kV]
12 Side2:PTR
[-100 to 0/0.1 μa]
13 Side2:SepDC
[0 to 10/0.1 μa]
14 Side2:SepAC [8 to 12/0.1 kV]
