Group 2000
SM 5-71 D014/D015/D078/D079
Service
Tables
SP2430 – Up to SP2304 001: Threshold 1
SP2431 – More than SP2304 001 Threshold 1, up to SP23204 002 Threshold 2.
SP2432 – More than SP2304 002 Threshold 2, up to SP2304 003 Threshold 3
SP2433 – More than SP2304 003 Threshold 3, up to SP2304 004 Threshold 4
SP2434 – More than SP2304 004 Threshold 4, up to SP2305 005 Threshold 3
SP2435 – More than SP2304 005 Threshold 5
These settings apply 1) only where the image is created in black (in either
black-and-white or full-color mode) on plain paper at full speed.
1 ITB
7 Side1:PTR
8 Side1:SepDC
9 Side1:SepAC
12 Side2:PTR
13 Side2:SepDC
14 Side2:SepAC
[10 to200/ 1%]
2440 Norm:FC:LLL Plain Paper: FC Very Low
2441 Norm:FC:LL Plain Paper: FC Low
2442 Norm:FC:ML Plain Paper: FC Medium Low
2443 Norm:FC:MM Plain Paper: FC Medium Medium
2444 Norm:FC:MH Plain Paper: FC Medium High
2445 Norm:FC:HH Plain Paper: FC High
These SPs set the paper size correction coefficient for the image to paper transfer
bias threshold values calculated based on the reading of the absolute humidity
from the temperature/humidity sensor and the thresholds set with SP2304.
SP2440 – Up to SP2304 001: Threshold 1
SP2441 – More than SP2304 001 Threshold 1, up to SP23204 002 Threshold 2.
SP2442 – More than SP2304 002 Threshold 2, up to SP2304 003 Threshold 3
