Group 2000
SM 5-83 D014/D015/D078/D079
Service
Tables
2826 LEdge Cor:Sp2 FC
Leading Edge Correction for Special Paper 2: FC. These SPs do the following
settings when printing on Special Paper 2 in the full-color mode:
1) PTR: Sets the strength/timing of the correction coefficient for the application of
bias when the image is transferred from ITB.
2) SepDC, SepAC: Set the strength/timing of the dc and ac charges applied to
neutralize the charges on the belt and paper so they will separate more easily.
Note: SP2826 selects the strength of the bias coefficient, and SP2827 sets the
start timing of the bias application.
7 Side1:PTR
8 Side1:SepDC
9 Side1:SepAC
12 Side2:PTR
13 Side2:SepDC
14 Side2:SepAC
[0 to 250 / 1%]
2827 LEdge SWT:Sp2 FC
Leading Edge Switch Timing for Special Paper 2: FC. Sets the switch off timing of
SP2826. The selected value is the number of mm from the leading edge. Applies
only to printing in full-color mode on Special Paper 2.
2 PTR
3 SepDC
4 SepAC
[0 to 30/ 1 mm]
