Group 4000
D014/D015/D078/D079 5-144 SM
Set higher for smoother.
[0 to 7/1]
7 Brightness: 1-255
Set higher for darker, set lower for
lighter.
[1 to 255/1]
8 Contrast: 1-255
Set higher for more contrast, set lower
for less contrast.
[1 to 255/1]
9 Ind Dot Erase: 0(Off) 1-7 (Strong)
Use to remove individual dots in the
background if they appear. Set higher
for removal of more background.
[0 to 7/1]
4600
Display the ID of ASIC DFU
These SP codes display the readings of IDs read during automatic adjustment of
the SBU. If one of these IDs is incorrect, this triggers SC144.
1 VSBCNT
Displays the value read for VSBCNT during automatic SBU
adjustment.
2 DAGL_L
Displays the value read for DAGL_L_ID during automatic SBU
adjustment.
3 DAGL_F
Displays the value read for DAGL_F_ID during automatic SBU
adjustment.
4603
AGC Operation DFU
Touch [EXECUTE] to execute automatic gain control (AGC) for HP detection.
