Group 4000
SM 5-145 D014/D015/D078/D079
Service
Tables
4609
Gray Balance Adj Value R DFU
4610
Gray Balance Adj Value G DFU
4611
Gray Balance Adj Value B DFU
4615
Gray Balance Adj Value R DFU
4616
Gray Balance Adj Value G DFU
4617
Gray Balance Adj Value B DFU
These SP codes display the reference voltages stored in NVRAM at the factory
for Red, Green, and Blue before the machine was shipped. The SBU acquires
these settings every time the machine is switched on.
[-256 to +255/1]
4628
Gain Adj Range:R DFU
4629
Gain Adj Range:G DFU
4630
Gain Adj Range:B DFU
When switched on, these SP display the current range for the gain of RED,
GREEN, and BLUE in the ASCI on the SBU after white level adjustment every
time the machine is switched on.
1 FC:F:R (G, B)
3 FC:L:R (G, B)
5 BK:F:R (G, B)
7 BK:L:R (G, B)
