Ricoh D014 - Page 692

Group 4000
D014/D015/D078/D079 5-150 SM
4680
Gain Adj Value: R DFU
4681
Gain Adj Value: G DFU
4682
Gain Adj Value: B DFU
When switched on, these SP codes display the settings done at the factory for
Red (Green, Blue) O (ODD) and E (EVEN) gain in the ASIC on the SBU after
white level adjustment every time the machine is switched on.
4690
White Level Peak Data:R DFU
4691
White Level Peak Data:G DFU
4692
White Level Peak Data:G DFU
When switched on, these SP codes display E (EVEN) or O (ODD) for the white
level peak Red (Green, Blue) data after white level detection (AGC) after the
machine is switched on.
4693
Black Level Data:R DFU
4694
Black Level Data:G DFU
4695
Black Level Data:G DFU
When switched on, these SP codes display E (EVEN) or O (ODD) for the black
level check done in the SBU for RED after the machine is switched on.
