Group 4000
SM 5-151 D014/D015/D078/D079
Service
Tables
4800
DF Density Adj Value DFU
This SP adjusts the white shading parameter for scanning an image with the
ADF. Adjusts the density level if the ID of outputs from the DF and Platen mode
are different.
1 RED [1 to 200/1]
2 GREEN [1 to 200/1]
3 BLUE [1 to 200/1]
4802 Scanner Free Run
This SP sets the scanner in the free run mode for testing. The free run can be
set with the exposure lamp off or on.
1 DF mode :Lamp Off
2 DF mode :Lamp On
Touch [OFF] or [ON]
4804 Home Position Operation
Touch [Execute] to do the home position operation once.
4806
FL Correction On/Off DFU
4808
Result FL Detection DFU
4809
Result FL Correction DFU
