Group 4000
D014/D015/D078/D079 5-152 SM
4902 Disp ACC Data
This SP outputs the final data read at the end of ACC execution. A zero is
returned if there was an error reading the data.
1 R_DATA1 Photo C Patch Level 1 (8-bit)
2 G_DATA1 Photo M Patch Level 1 (8-bit)
3 B_DATA1 Photo Y Patch Level 1 (8-bit)
4 R_DATA2 Photo C Patch Level 17 (8-bit)
5 G_DATA2 Photo M Patch Level 17 (8-bit)
6 B_DATA2 Photo Y Patch Level 17 (8-bit)
[0 to 255/1]
4904 Test Scan IPU
Test Scanner IPU Board
This SP tests the components of the BICU:
Test 1 performs write and read tests the CPU by conducting a compare
check that reads and writes to each register of the ASIC.
Test 2 performs a check of the image paths and connections and displays the
location of a defect of an error is detected.
1 Test 1
2 Test 2
[0 to 65535/1]
4905 Select Gradation Level
This SP changes the threshold parameters of error diffusion.
[0 to 255/1]
