Group 5000
D014/D015/D078/D079 5-186 SM
243 Bk Cleaning Motor: Half Speed 1
244 M Cleaning Motor: Half Speed 1
245 C Cleaning Motor: Half Speed 1
246 Y Cleaning Motor: Half Speed 1
247 ITB Motor: Half Speed 1
248 PTR Motor: Half Speed 1
249 Fusing/Exit Motor: Half Speed 1
5810 Cancel Fusing SC
When the machine issues one of the "Level A" SC codes shown below, this
indicates a serious problem in the fusing unit. The machine is disabled and the
operator cannot reset the SC. The machine requires servicing immediately.
Touch [EXECUTE] release the machine for servicing.
SC542 – SC545 Heating roller thermistor 1
SC547 – Zero Cross
SC548 – SC550 Heating roller thermistor 2
SC551 – Pressure roller thermistor
SC553 – SC555 Pressure roller thermistor
SC662 – SC565 Hot roller thermistor
5811 Machine Serial
This SP displays the machine serial number.
