Group 5000
D014/D015/D078/D079 5-234 SM
200 Detect Mem Leak
201 DocSvr Timeout
5887 SD Get Counter
This SP sends a text file to an SD card inserted in Slot 1 (lower slot). The
operation stores. The file is stored in a folder created in the root directory of the
SD card called SD_COUNTER. The file is saved as a text file (*.txt) prefixed with
the number of the machine.
1. Insert the SD card in SD card lower slot.
2. Select SP5887 then touch [EXECUTE].
3. Touch [Execute] in the message when you are prompted.
5888*
Personal Information Protect
Selects the protection level for logs.
[0 to 1 / 0 / 1}
0: No authentication, No protection for logs
1: No authentication, Protected logs (only an administrator can see the logs)
5894 [External Charge Unit Setting] Used with the external key counter/coin counter
using the optional 20 Interface Unit Type A 20 pin connection.
001 Switch Charge Mode
[0 to 2 / 0 / 1step]
Pattern 0 (SP5-894-001=0: Default setting) Default pattern which allows
separate counter for print, FAX (reception), B/W copy, and Full-color copy.
Pattern 1 (SP5-894-001=1) Separate counter for B/W and color is available
under this pattern. However, it is not possible to distinguish between Copier and
Printer outputs.
Pattern 2 (SP5-894-001=2) With this setting, it is possible to distinguish between
B/W and color outputs for both the Copier and Printer. However, it is not possible
to manage FAX reception documents.
Rev. 11/12/2009
⇒
To Next Page
