5.7 GROUP 6000
6006 ADF Reg Adj
ADF Registration Adjustment
1 ADF Main Reg Ad: Front
Adjusts the side-to-side registration for the
front/back in ADF mode.
[–3 to +3/0.1 mm]
2 ADF Main Reg Ad: Back
3 ADF Sub Reg Adj
Adjusts the vertical registration for the front/back in
ADF mode.
[–29 to +29/0.17 mm]
-29 = -4.93 mm
+29 = +4.93 mm
5 ADF Buck Adj:Front
Adjusts the roller timing at the skew correction
sensor/entrance roller. A higher setting causes
more buckling.
[–10.0 to +20/0.25 mm]
-20 = -5.0 mm
+20 = +5.0 mm
6 ADF Buck Adj:Back
Adjusts the roller timing at the interval
sensor/scanning roller. A higher setting causes
more buckling.
[–16.0 to +23/0.13 mm]
-16 = -2 mm
+23 = +3 mm
7 ADF TEdge EMargin
These settings adjust the erase margin for the
trailing edges for the front/back.
[–20 to +20/0.5 mm]
-20 = -10 mm
+20 = +10 mm
