Group 6000
D014/D015/D078/D079 5-240 SM
6007 ADF Input Chk
Displays signals received from sensors and switches in the ADF. The signals are
reflected in an 8-bit array:
(7) 0000 0000 (0)
where 0 and 1 are used to define the state of each sensor
 0: No detect
 1: Detect
1 ADF Group 1
Bit Sensor
7 Registration Sensor
6 Interval Sensor
5 Skew Correction Sensor
4 Separation Sensor
3 Original Set Sensor
2 B5 Detection Sensor
1 A4 Detection Sensor
0 LG Detection Sensor
2 ADF Group 2
Bit Sensor
7 APS Start Sensor
6 ARDF Position Sensor
5 Exit Sensor
4 Paper Width Sensor 5
