Group 6000
SM 5-241 D014/D015/D078/D079
Service
Tables
3 Paper Width Sensor 4
2 Paper Width Sensor 3
1 Paper Width Sensor 2
0 Paper Width Sensor 1
3 ADF Group 3
Bit Sensor
7 Not used
6 Not used
5 Lower Inverter Sensor
4 Inverter Switchback Sensor
3 Bottom Plate Position Sensor
2 to 0 Not used
6008 ADF Output Chk
Turns on the ADF electrical components individually for testing.
1 ADF Feed M:Fwd
2 ADF Feed M:Rev
3 ADF Trans M:Fwd
4 ADF Ext M:Fwd
5 ADF Top Inv M:Fwd
6 ADF Top Inv M:Rev
7 ADF Bot Inv M:Fwd
8 ADF Bot Inv M:Rev
9 ADF Pickup M:Fwd
