6115 Input Check:Fin1 2000/3000-Sheet Finishers D373/D374
Use these SP codes to perform the input checks for either the 2000-Sheet
Finisher D373 or 3000-Sheet Finisher D374.
The following abbreviations are used below:
 Sn: Sensor
 HP: Home Position
 Stp: Staple
 BStapler: Booklet Stapler (D373 only)
1 Entrance Sn
2 Proof Exit Sn
3 Proof Full Sn
4 Up Tray Exit Sn
5 Staple Exit Sn
6 Shift Roll HP Sn
7 Exit Sn
8 Exit Guide HP Sn
9 Low Tray Hgt Sn
10 Up Tray Hgt Sn
11 Up Tray Full Sn
12 Stack Roll HP Sn
13 Jogger HP Sn
14 Feed Out HP Sn
