Group 6000
D014/D015/D078/D079 5-258 SM
4 Other
155 Staple Stack Jogging
Touch [1:+1 Time] to have the jogger fences press against the sides of the stack
on the staple tray one more time to align the stack for corner stapling.
[*0:Default] [1:+1 Time]
6156 Input Check:Fin2 3000-Sheet Finisher B830
Use these SP codes to perform the input checks for either the 3000-Sheet
Finisher B830. The following abbreviations are used below:
Sn: Sensor
Hgt: Height
HP: Home Position
Stp: Staple
BStapler: Booklet Stapler (D373 only)
1 Entrance Sn
2 Proof Exit Sn
3 Shift Exit Sn 1
4 Stp Exit Sn
5 Tray Bot Plt Sn
6 Tray Near Bot Sn
7 Release HP Sn
8 Jogger HP Sn
9 Shift HP Sn 1
10 Stapler Side HP Sn
11 Stapler HP Sn
12 Stapler Sn
13 Stapler Tray Sn
Rev. 08/2008
