Group 6000
D014/D015/D078/D079 5-264 SM
4 Paper Detect Sn 2
5 Vert Transport Sn2:Bin3
6 Paper Overflow Sn 2
7 Paper Detect Sn 3
8 Paper Overflow Sn 3
9 Paper Detect Sn 4
10 Vert Transport Sn3:Bin5
11 Paper Overflow Sn 4
12 Paper Detect Sn 5
13 Paper Overflow Sn 5
14 Paper Detect Sn 6
15 Vert Transport Sn4:Bin7
16 Paper Overflow Sn 6
17 Paper Detect Sn 7
18 Paper Overflow Sn 7
19 Paper Detect Sn 8
20 Vert Transport Sn 5:Bin9
21 Paper Overflow Sn 8
22 Paper Detect Sn 9
23 Paper Overflow Sn 9
24 Door Open Switch
6351 Output Check:Mail Box 9-Bin Mailbox B762
