Ricoh D014 - Page 807

Group 6000
SM 5-265 D014/D015/D078/D079
Service
Tables
the mailbox.
1 Vert Transport Motor
2 Junction Gate SOL1
3 Turn Gate SOL1
4 Turn Gate SOL2
5 Turn Gate SOL3
6 Turn Gate SOL4
7 Turn Gate SOL5
8 Turn Gate SOL6
9 Turn Gate SOL7
10 Turn Gate SOL8
6352 Free Run:Mail Box
Press [ON] and [OFF] to switch on/off the mailbox for free run testing.
6400 Input Check: 2-Tray CIT Cover Interposer Tray B835
Use these SP codes to perform the sensor and switch input checks for the
Cover Interposer Tray B835.
1 Feed Sn1
2 Feed Sn2
3 Pullout Sn1
4 Pullout Sn2
5 Trans Sn1
6 Trans Sn2
Rev. 08/2008
