Group 7000
D014/D015/D078/D079 5-274 SM
98 Paper Type Paper Type
99 Bypass Paper Feed Sn Bypass Paper Feed Sensor
7504 Paper Jam Loc 2000-Sheet Finishers D373
Displays the list of possible locations where a jam could have occurred. Press
the appropriate key to display the jam count for that location. These jams are
caused by the failure of a sensor to activate.
On Operation Panel Actual Component Name
121 Entrance Jam Entrance Sensor
122 Proof Tray Exit Proof Tray Exit Sensor
123 Shift Tray Exit Shift Tray Exit Sensor
124 Stapler Exit Stapler Exit Sensor
125 Exit After Jogging Exit Sensor After Jogging
126 Corner Stapling Corner Stapling: Stapler Unit 1
127 Saddle Stapling Saddle-Stitch Stapler Unit
128 Paper Folding Paper Folding
129 Shift Tray Motor Shift Tray Motor
130 Jog Fence Motor Jogger Fence Motor
131 Shift Roller Motor Shift Roller Motor
132 Stapler Shift M Stapler Shift Motor
133 Stapler M Stapler Motor: Unit 2
134 Folder Plate M Folder Plate Motor
135 Feed Out Belt M Feed Out Belt Motor
136 Paper Punch Motor Paper Punch Motor
