Group 7000
SM 5-275 D014/D015/D078/D079
Service
Tables
137 Z-Folding Z-Fold Jam
7504 Paper Jam Loc (Fin2) 3000-Sheet Feeder B830
Displays the list of possible locations where a jam could have occurred. Press
the appropriate key to display the jam count for that location. These jams are
caused by the failure of a sensor to activate.
On Operation Panel Actual Component Name
141 Entrance Sn Entrance Sensor
142 Proof Tray Exit Sn Proof Tray Exit Sn
143 Shift Exit Sn Shift Exit Sn
144 Stapler Exit Stapler Exit Sensor
145 Feed Out Feed Out
148 Upper Trans M Upper Transport Motor
149 Shift Tray Motor Shift Tray Motor
150 Jogger Fence Motor Jogger Fence Motor
151 Shift Roller Motor Shift Roller Motor
153 Stapling Motor Stapling Motor
154 Pre-Stack Jam
155 Feed Out Belt Motor Feed Out Belt Motor
156 Paper Punch Motor Paper Punch Motor
157 Z-Fold Motor Jam
