Group 7000
D014/D015/D078/D079 5-278 SM
7504 Paper Jam Loc 3000-Sheet Finisher D374
Displays the list of possible locations where a jam could have occurred. Press
the appropriate key to display the jam count for that location. These jams are
caused by the failure of a sensor to activate.
On Operation Panel Actual Component Name
191 Entrance Sn Entrance Sensor
192 Stapler Exit Stapler Exit Sensor
193 Shift Exit Sn Shift Exit Sensor
194 Stapler Exit Stapler Exit Sensor
195 Belt Feed Out Belt Feed Out
198 Paper Folding Paper Folding
199 Shift Tray Motor Shift Tray Motor
200 Jogger Fence Motor Jogger Fence Motor
201 Shift Roller Motor Shift Roller Motor
202 Stapler Shift M Stapler Shift Motor
203 Stapling Motor Stapling Motor
204 Paper Folding Paper Folding
205 Feed Out Belt Motor Feed Out Belt Motor
206 Paper Punch Motor Paper Punch Motor
207 Insufficient Data
