7504 Paper Jam Loc (Z-Folder) Z-Folding Unit B660
Displays the list of possible locations where a jam could have occurred. Press
the appropriate key to display the jam count for that location. These jams are
caused by the failure of a sensor to activate.
On Operation Panel Actual Component Name
211 Paper Feed:Late Paper Feed Sensor: Late
212 Paper Feed:Lag Paper Feed Sensor: Lag
213 Fold Timing Sn:Late Fold Timing Sensor: Late
214 Fold Timing Sn:Lag Fold Timing Sensor: Lag
215 Lead Edge Sn:Late Leading Edge Sensoor:Late
216 Lead Edge Sn:Lag Leading Edge Sensor:Lag
217 Up Stopper Sn:Late Upper Stopper Path Sensor:Late
218 Up Stopper Sn:Lag Upper Stopper Path Sensor:Lag
219 Lower Ex Sn:Late Lower Exit Sensor:Late
220 Lower Ex Sn1:Lag Lower Exit Sensor:Lag
223 Up Ex Sn:Late Upper Exit Sensor:Late
224 Up Ex Sn:Lag Upper Exit Sensor:Lag
225 Paper Fold M Paper Fold Motor
226 Lower Stopper M Lower Stopper Motor Lock
227 Upper Stopper M Upper Stopper Motor Lock
