Group 7000
D014/D015/D078/D079 5-280 SM
7504 Paper Jam Loc Cover Interposer Tray B835
Displays the list of possible locations where a jam could have occurred. Press
the appropriate key to display the jam count for that location. These jams are
caused by the failure of a sensor to activate.
On Operation Panel Actual Component Name
230 Tray 1: No Feed
231 Tray 2: No Feed
232 Tray 1: Grip Sn
233 Tray 2: Grip Sn
234 Tray 1: Trans Jam
235 Tray 2: Trans Jam
236 Exit Jam
237 Entrance Sn Jam
238 Exit Sn Jam
239 Tray 1: Lift Motor
240 Tray 2: Lift Motor
241 Tray 1: Pickup Motor
242 Tray 2: Pickup Motor
To Next Page
