Group 7000
SM 5-281 D014/D015/D078/D079
Service
Tables
7505 Original Jam Det (ARDF)
Displays the list of possible locations where a jam could have occurred. Press
the appropriate key to display the jam count for that location. These jams are
caused by the failure of a sensor to activate.
On Operation Panel Actual Component Name
1 At Power On At Power On
3 Separation Sn:Late Separation Sensor:Late
4 Skew Cor Sn:Late Skew Correction Sensor:Late
5 Interval Sn:Late Interval Sensor:Late
6 Reg Sn:Late Registration Sensor:Late
7 Exit Sn:Late Exit Sensor:Late
8 Inv Switch Sn:Late Inverter Switchback Sensor:Late
9 Low Inv Sn:Late Lower Inverter Sensor:Late
53 Separation Sn:Lag SeparationsSensor:Lag
54 Skew Cor Sn:Lag Skew Correction Sensor:Lag
55 Interval Sn:Lag Interval Sensor:Lag
56 Reg Sn:Lag Registration Sensor:Lag
57 Exit Sn:Lag Exit Sensor:Lag
58 Inv Switch Sn:Lag Inverter Switchback Sensor:Lag
59 Low Inv Sn:Lag Lower Inverter Sensor:Lag
