Command reference
R&S
®
ZNB/ZNBT
1012User Manual 1173.9163.02 ─ 62
Parameter Circuit model Pictogram
SGLS Shunt C, serial Ls
SGGS Shunt C, serial Cs
Table 7-8: Circuit models for port set de-/embedding
Parameter Circuit model Pictogram
FIMPort File import, no circuit model
STSL, ..., SGGS The models for port pairs (i.e. port sets with two ports) are the same as the ones for balanced
ports
See Table 7-7.
Table 7-9: Circuit models for ground loop de-/embedding
Parameter Circuit model Pictogram
FIMPort File import, no circuit model
SL Shunt L
SCPI command reference
