R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
1068User Manual 1173.9163.02 ─ 62
CONFigure:CHANnel<Ch>:MEASure[:STATe] <Boolean>
Enables or disables the sweep in channel no. <Ch>. This command can be used to
restrict the measurement in a subset of channels in order to optimize the measurement
speed.
Suffix:
<Ch>
.
Number of an existing channel.
Parameters:
<Boolean> ON | OFF
*RST: ON (all existing channels)
Example:
*RST; :CONFigure:CHANnel2 ON; CHANnel3 ON
Create channels 2 and 3, in addition to the default channel no.
1. The analyzer performs sweeps in all three channels.
CONFigure:CHANnel:MEASure:ALL OFF
Disable the measurement in all channels
CONFigure:CHANnel2:MEASure ON
(Re-)enable the measurement in channel no. 2. The analyzer
measures in channel 2; the channels no. 1 and 3 are not mea-
sured.
Manual operation: See "Continuous / Single" on page 442
CONFigure:CHANnel<Ch>:NAME <ChannelName>
Assigns a name to channel number <Ch>. The channel must be created before
(CONFigure:CHANnel<Ch>[:STATe] ON). Moreover it is not possible to assign the
same name to two different channels. CONFigure:CHANnel:CATalog? returns a list
of all defined channels with their names.
Suffix:
<Ch>
.
Number of an existing channel.
Parameters:
<ChannelName> Channel name, e.g. 'Channel 4'.
*RST: 'Ch1'
Example: See CONFigure:CHANnel:CATalog?
Manual operation: See "Channel table" on page 550
CONFigure:CHANnel<Ch>:NAME:ID? <ChannelName>
Queries the channel number (numeric suffix) of a channel with known channel name. A
channel name must be assigned before (CONFigure:CHANnel<Ch>:NAME
<ChannelName>). CONFigure:CHANnel:CATalog? returns a list of all defined
channels with their names.
Suffix:
<Ch>
.
Channel number. This suffix is not relevant and may be omitted
(the command returns the actual channel number).
SCPI command reference
