Command reference

R&S

ZNB/ZNBT

1070User Manual 1173.9163.02 ─ 62

CONFigure:CHANnel<Ch>:TRACe:REName <TraceName>

Assigns a (new) name to the active trace in channel <Ch>.

Suffix:

<Ch>

Channel number

Setting parameters:

<TraceName> Trace name, e.g. 'Trace 4'.

Example:

*RST; :CONF:CHAN:TRAC:REN 'Testtrace_1'

Reset the analyzer to create a default trace in channel 1 and set

this trace as the active trace. Rename the trace 'Testtrace_1'.

CALC:PAR:SDEF 'Testtrace_2', 'S11'

Create a new trace which will become the active trace in chan-

nel no. 1.

CONF:TRAC:REN 'Testtrace_1', 'Testtrace_3'

Rename the first trace (which is currently not active) 'Test-

trace_3'.

Usage: Setting only

Manual operation: See "Table Area" on page 337

CONFigure:TRACe:CATalog?

Returns the numbers and names of all traces in the current recall set. The response is

a string containing a comma-separated list of trace numbers and names, see example

below. If all traces have been deleted the response is an empty string ("").

Tip: Use CONFigure:CHANnel<Ch>:TRACe:CATalog? to query the traces in a par-

ticular channel; see example.
