Command reference
R&S
®
ZNB/ZNBT
1071User Manual 1173.9163.02 ─ 62
Example:
*RST; :CALC2:PAR:SDEF 'Ch2Trc2', 'S11'
Create channel 2 and a new trace named Ch2Trc2.
CONF:TRAC:CAT?
Query all traces and their names. As a default trace no. 1 is cre-
ated upon *RST, the response is '1,Trc1,2,Ch2Trc2'.
CONF:CHAN1:TRAC:CAT?
Query the channels in channel no. 1. The response is
'1,Trc1'.
CONF:TRAC:NAME:ID? 'Ch2Trc2'
Query the trace number for the trace named "Ch2Trc2". The
response is 2.
CONF:TRAC2:NAME?
Query the trace name for trace no. 2. The response is
'Ch2Trc2'.
CONF:TRAC:CHAN:NAME? 'Ch2Trc2'
Query the channel name for trace Ch2Trc2. The response is
'Ch2'.
CONF:TRAC:CHAN:NAME:ID? 'Ch2Trc2'
Query the channel number for trace Ch2Trc2. The response is
2.
Usage:
Query only
Manual operation: See "Table Area" on page 337
CONFigure:TRACe<Trc>:CHANnel:NAME? <TraceName>
Queries the channel name for an existing trace named '<TraceName>'.
Suffix:
<Trc>
.
Trace number. This suffix is ignored; the trace is referenced by
its name.
Query parameters:
<TraceName> Trace name, e.g. 'Ch2Trc2'.
Example: See CONFigure:TRACe:CATalog?
Usage: Query only
Manual operation: See "New Channel" on page 548
CONFigure:TRACe<Trc>:CHANnel:NAME:ID? <TraceName>
Queries the channel number (numeric suffix) for an existing trace named
'<TraceName>'.
Suffix:
<Trc>
.
Trace number. This suffix is ignored; the trace is referenced by
its name.
Query parameters:
<TraceName> Trace name, e.g. 'Ch2Trc2'.
SCPI command reference
