Example: See CONFigure:TRACe:CATalog?
Usage: Query only
Manual operation: See "New Channel" on page 548
CONFigure:TRACe<Trc>:NAME <TraceName>
Assigns a name to an existing trace number <Trc>. Note that it is not possible to
assign the same name to two different traces. CONFigure:TRACe:CATalog? returns
a list of all traces in the active recall set with their names.
Suffix:
<Trc>
.
Number of an existing trace.
Parameters:
<TraceName> Trace name, e.g. 'Ch2Trc2'.
*RST: 'Trc1'
Example: See CONFigure:TRACe:CATalog?
CONFigure:TRACe<Trc>:NAME:ID? <TraceName>
Queries the trace number (numeric suffix) of a trace with known trace name.
CONFigure:TRACe:CATalog? returns a list of all traces in the active recall set with
their names.
Suffix:
<Trc>
.
Trace number. This suffix is not relevant and may be omitted
(the command returns the actual trace number).
Query parameters:
<TraceName> Trace name, e.g. 'Ch2Trc2'.
Example: See CONFigure:TRACe:CATalog?
Usage: Query only
CONFigure:TRACe<Trc>:REName <OldTraceName>, <NewTraceName>
Assigns a new name to a trace. The trace does not have to be the active trace.
Suffix:
<Trc>
.
Trace number. This suffix is ignored; the trace is identified via its
<TraceName>
Setting parameters:
<OldTraceName> String parameter with old trace name, e.g. 'Trc1'
<NewTraceName> String parameter with new trace name, e.g. 'S11 Trace'
*RST: n/a
Example: See CONFigure:CHANnel<Ch>:TRACe:REName
