Command reference
R&S
®
ZNB/ZNBT
1073User Manual 1173.9163.02 ─ 62
Usage: Setting only
Manual operation: See "Table Area" on page 337
CONFigure:TRACe:WINDow? <TraceName>
Returns the trace number within a diagram which is assigned to the trace
<TraceName> is assigned to. A zero is returned when the trace is not assigned/
displayed.
The trace number is equal to the <WndTr> suffix in DISPlay[:WINDow<Wnd>]:
TRACe<WndTr>:FEED and similiar commands; see example.
Query parameters:
<TraceName> Trace name (string), e.g. 'Trc1'
Example: See CONFigure:TRACe:WINDow:TRACe?
Usage: Query only
CONFigure:TRACe:WINDow:TRACe?
<TraceName>
Returns the number of the diagram which the trace <TraceName> is assigned to. A
zero is returned when the trace is not assigned/displayed.
The diagram number is equal to the <Wnd> suffix in DISPlay[:WINDow<Wnd>]:
TRACe<WndTr>:FEED and similar commands; see example.
Query parameters:
<TraceName> Trace name (string), e.g. 'Trc1'
Example:
*RST; :CALC:PAR:SDEF 'Trc2', 'S11'
Create a trace named Trc2.
CONF:TRAC:WIND:TRAC? 'Trc2'
Query the diagram number for Trc2. The new trace is not dis-
played, so the response is 0.
DISP:WIND2:STAT ON
Create a diagram no. 2.
DISP:WIND2:TRAC3:FEED 'Trc2'
Display the trace in the new diagram no. 2, assigning the trace
number 3.
CONF:TRAC:WIND? 'Trc2'
Query the diagram number for Trc2. The response is 2.
CONF:TRAC:WIND:TRAC? 'Trc2'
Query the trace number for Trc2. The response is 3.
Usage:
Query only
Manual operation: See "Table Area" on page 337
