Command reference
R&S
®
ZNB/ZNBT
1156User Manual 1173.9163.02 ─ 62
MMEMory:LOAD:RIPPle <TraceName>, <RippleLimFile>
Loads a ripple limit definition from a specified file and assigns it to a trace with a speci-
fied name. Ripple limits are created using the CALCulate<Ch>:RIPPle... com-
mands.
Setting parameters:
<TraceName> Name of an existing trace in the active setup (string parameter).
The imported ripple limit line is assigned to this trace, irrespec-
tive of the trace information in the ripple limit file.
*RST: -
<RippleLimFile> String parameter to specify the name and directory of the ripple
limit file to be loaded. The default extension (manual control) for
ripple limit files is *.ripple, although other extensions are allowed.
If no path is specified the analyzer searches the current direc-
tory, to be queried with MMEMory:CDIRectory
Example: Assume that the current setup contains two traces named Trc1
and Trc2, respectively, and that ripple limits have been defined
for Trc1.
MMEM:STOR:RIPP 'TRC1', 'C:
\Users\Public\Documents
\Rohde-Schwarz\Vna\LIMitLines\Lim_Trc1.limit'
Store the ripple limit definition of Trc1 to a ripple limit file.
MMEM:LOAD:RIPP 'TRC2', 'C:
\Users\Public\Documents
Rohde-Schwarz\Vna\LIMitLines\Lim_Trc1.limit'
Load the previously created ripple limit file and assign the limits
to Trc2.
CALC:RIPP:DISPlay ON
Show the ripple limit line for the active trace in the diagram.
Usage:
Setting only
Manual operation: See "Recall Ripple Test.../Save Ripple Test..." on page 385
MMEMory:LOAD:SEGMent <Channel>, <SweepSegFile>
Replaces the related channel's current sweep segment definition by a sweep segment
definition loaded from the specified ASCII file.
Setting parameters:
<Channel> Channel number
<SweepSegFile> String parameter to specify the name and directory of the sweep
segment file to be loaded. The default extension (manual con-
trol) for sweep segment files is *.SegList, although other
extensions are allowed.
If no path is specified the analyzer searches the current direc-
tory, to be queried with MMEMory:CDIRectory
