Command reference
R&S
®
ZNB/ZNBT
1197User Manual 1173.9163.02 ─ 62
[SENSe:]CORRection:CKIT:CATalog? [<ConnectorType>]
Returns a list of all cal kits for a given connector type or for all connector types.
Query parameters:
<ConnectorType> Name of the connector type (optional). Use [SENSe<Ch>:
]CORRection:CONNection:CATalog? to query connector
names.
If omitted, the command returns the list of all cal kits.
Example: See [SENSe<Ch>:]CORRection:CONNection:CATalog?
Usage: Query only
Manual operation: See "Available Cal Kits" on page 515
[SENSe:]CORRection:CKIT:DELete <CalKitName>
Deletes an imported or user-defined cal kit.
Note: It is not possible to modify or store predefined or ideal kits.
Setting parameters:
<CalKitName> String parameter containing an imported or user-defined calibra-
tion kit available on the analyzer.
Example: See [SENSe:]CORRection:CKIT:LABel
Usage: Setting only
Manual operation: See "Add / Copy / Delete / Standards..." on page 515
[SENSe:]CORRection:CKIT:DMODe <ConnectorType>, <CalKitName>, <KitLabel>,
<Mode>
Sets/gets the delay mode for the related cal kit (identified by connector type, name and
label), i.e allows to toggle between ZVR compatible and Keysight modelling (see "Off-
set Parameters" on page 518). Subsequent standard definitions interpret the specified
<DelayParam> accordingly.
In "set direction", if a cal kit with the given connector type, name and label is not availa-
ble on the analyzer, it is created automatically.
Cal kits that are not created/modified using [SENSe:]CORRection:CKIT:DMODe use
the ZVR compatible modelling.
Parameters:
<ConnectorType> Name of the connector type. Use [SENSe<Ch>:
]CORRection:CONNection:CATalog? to query connector
names.
<CalKitName> String parameter containing the name of the calibration kit. See
"Cal kit naming conventions " under [SENSe:]CORRection:
CKIT:<ConnType>:LSELect.
SCPI command reference
