Command reference
R&S
®
ZNB/ZNBT
1286User Manual 1173.9163.02 ─ 62
Parameters:
<DUTLength> Default unit: s
Options: R&S ZNB/ZNBT-K20
Manual operation: See "Max. DUT Measure Delay / Max. El. Length / Max. Mech.
Length" on page 687
[SENSe<Ch>:]HARMonic:ELENgth:DATA <DUTELength>
Sets/gets the expected maximum electrical length of the DUT.
The set command automatically activates the "Automatic Harmonic Grid" function, i.e.
it sets [SENSe<Ch>:]HARMonic:AUTO to ON.
Suffix:
<Ch>
.
Channel number
Parameters:
<DUTELength> Default unit: m
Options: R&S ZNB/ZNBT-K20
Manual operation: See "Max. DUT Measure Delay / Max. El. Length / Max. Mech.
Length" on page 687
[SENSe<Ch>:]HARMonic:MLENgth:DATA <DUTMLength>
Sets/gets the expected maximum mechanical length of the DUT.
The set command automatically activates the "Automatic Harmonic Grid" function, i.e.
it sets [SENSe<Ch>:]HARMonic:AUTO to ON.
Suffix:
<Ch>
.
Channel number
Parameters:
<DUTMLength> Default unit: m
Options: R&S ZNB/ZNBT-K20
Manual operation: See "Max. DUT Measure Delay / Max. El. Length / Max. Mech.
Length" on page 687
[SENSe<Ch>:]HARMonic:PERMittivity:DATA <DUTPermittivity>
Sets/gets the (relative) permittivity of the DUT.
The set command automatically activates the "Automatic Harmonic Grid" function, i.e.
it sets [SENSe<Ch>:]HARMonic:AUTO to ON.
Suffix:
<Ch>
.
Channel number
Parameters:
<DUTPermittivity>
