R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
1375User Manual 1173.9163.02 ─ 62
SOURce<Ch>:POWer<PhyPt>:PERManent[:STATe] <Boolean>
Defines whether the source power is permanently on ("generator port").
For the R&S ZNBT, among the analyzer ports driven by the same internal source, more
than one can operate as generator port. However, all these ports must have identical
arbitrary frequency and power settings. If
SOURce<Ch>:POWer<PhyPt>:PERManent:STATe is set to ON, then for channel
<Ch> the arbitrary frequency and power settings of port <PhyPt> are copied all ports
driven by the same internal source.
Note:
If External switch matrices are part of the RF connection configuration, operation with
more than one internal source is not supported. In this case only external generators
can be used as permanent signal sources.
Suffix:
<Ch>
.
Channel number
<PhyPt> Test port number of the analyzer
Parameters:
<Boolean> ON - power at port <PhyPt> is permanently on.
OFF - power is only on for the partial measurements that require
the port as a drive port.
*RST: OFF
Example:
SOUR:POW2:STAT ON
Switch the RF power at port no. 2 on.
SOUR:POW2:PERM ON
Activate a permanent signal source.
Manual operation: See "Gen" on page 563
SOURce:POWer:REDuce:SDELay <SettlingDelay>
Deprecated; superseded by SOURce:POWer:SWEepend:SDELay
If power reduction at sweep end is enabled (SOURce<Ch>:POWer<PhyPt>:
REDuce[:STATe] ON) this defines the settling delay at subsequent sweep starts, i.e.
the time between power-up and sweep start when a new sweep is requested.
This is a global setting.
Parameters:
<SettlingDelay> Settling delay
Default unit: s
Example: See SOURce:POWer:SWEepend:MODE on page 1377
SOURce<Ch>:POWer<PhyPt>:REDuce[:STATe] <ReduceAtSweepEnd>
Deprecated; superseded by SOURce:POWer:SWEepend:MODE
SCPI command reference
