R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
1401User Manual 1173.9163.02 ─ 62
Note: a manual RF connection configuration must be performed within a transaction,
enclosed by the commands SYSTem:COMMunicate:RDEVice:SMATrix:
CONFigure:STARt and SYSTem:COMMunicate:RDEVice:SMATrix:CONFigure:
END. The modified configuration will not be applied until the end of this transaction.
The new configuration is discarded, i.e. the previous configuration remains active ("roll-
back"). The transaction wil be terminated.
Usage: Event
SYSTem:COMMunicate:RDEVice:SMATrix:CONFigure:END
Ends a manual RF connection configuration: if the configuration is valid, it will be acti-
vated ("commit"). Otherwise an error is returned and the new configuration is discar-
ded, i.e. the previous configuration remains active ("rollback").
In any case the transaction will be terminated.
Note: a manual RF connection configuration must be performed within a transaction,
enclosed by the commands SYSTem:COMMunicate:RDEVice:SMATrix:
CONFigure:STARt and SYSTem:COMMunicate:RDEVice:SMATrix:CONFigure:
END. The modified configuration will not be applied until the end of this transaction.
The configuration is valid if
●
every VNA port is either connected to a matrix port or directly assigned to a DUT
test port
●
every matrix that is part of the configuration is connected to the VNA by at least
one RF connection
●
every VNA port that is not connected to a matrix is assigned to a test port
●
the test ports are numbered consecutively, starting with 1
Example:
See SYSTem:COMMunicate:RDEVice:SMATrix:
CONFigure:STARt
Usage: Event
SYSTem:COMMunicate:RDEVice:SMATrix:CONFigure:STARt
Starts a manual RF connection configuration.
Note: a manual RF connection configuration must be performed within a transaction,
enclosed by the commands SYSTem:COMMunicate:RDEVice:SMATrix:
CONFigure:STARt and SYSTem:COMMunicate:RDEVice:SMATrix:CONFigure:
END. The modified configuration will not be applied until the end of this transaction.
An RF connection configuration comprises the RF connections between the VNA, a set
of switch matrices and the DUT test ports.
SCPI command reference
