R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
1412User Manual 1173.9163.02 ─ 62
SYSTem:CORRection:JOINcal <FirstCal>, <LocationFirstCal>, <SecondCal>,
<LocationSecondCal>[, <OutputCal>[, <LocationOutputCal>]]
Command for joining calibrations.
●
The query returns whether if the two calibrations <FirstCal> (from <LocationFirst-
Cal>) and <SecondCal> (from <LocationSecondCal>) are joinable.
●
The set command tries to join the two calibrations.
If successful, it stores the resulting calibration as <OutputCal> in <LocationOutput-
Cal>.
Parameters:
<FirstCal> String parameter with the channel name (for <LocationFirst-
Cal>=CHANnel) or the calibration file name (for <LocationFirst-
Cal>=POOL) of the first calibration.
<LocationFirstCal> CHANnel | POOL
<SecondCal> String parameter with the channel name (for <LocationSecond-
Cal>=CHANnel) or the calibration file name (for <LocationSe-
condCal>=POOL) of the first calibration.
<LocationSecondCal>CHANnel | POOL
Setting parameters:
<OutputCal> String parameter with the channel name (for <LocationOutput-
Cal>=CHANnel) or the calibration file name (for <LocationOut-
putCal>=POOL) of the resulting calibration.
Note: If (<OutputCal>,<LocationOutputCal>) matches one of the
input calibrations, this input calibration is replaced.
<LocationOutputCal> CHANnel | POOL
Return values:
<Joinable>
Manual operation: See "Input Calibration1/Input Calibration2/Cal Name"
on page 537
SYSTem:CORRection:WIZard[:IMMediate] <Dialogs>
Keysight-compatible command to open the Start Cal tab or the Calibration Kits dialog.
Tip: When working with the Chapter 6.1.3, "GPIB Explorer", on page 805, switch to
raw mode ("Options">"Raw mode" in the IECWIN32 GUI) before executing this com-
mand.
Setting parameters:
<Dialogs> MAIN | CKIT
MAIN: open the "Calibration > Start Cal" softtool tab
CKIT: open the "Calibration Kits" dialog
Usage: Setting only
SCPI command reference
