R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
1430User Manual 1173.9163.02 ─ 62
Table 7-18: Reserved Trace Names
Parameter Meaning Used in
CH1DATA
CH2DATA
CH3DATA
CH4DATA
Active data trace of channels
1 to 4
TRACe:COPY
TRACe[:DATA]:STIMulus[:ALL]?
TRACe[:DATA][:RESPonse][:ALL]?
CALCulate<Chn>:MATH[:EXPRession][:
DEFine]
CH1MEM
CH2MEM
CH3MEM
CH4MEM
Active memory trace associ-
ated to the active data trace
CH1DATA, CH2DATA,
CH3DATA, CH4DATA, respec-
tively.
TRACe[:DATA]:STIMulus[:ALL]?
TRACe[:DATA][:RESPonse][:ALL]?
IMPLied
Active data trace, addressed
with <Chn>
CALCulate<Chn>:MATH[:EXPRession][:
DEFine]
CHMem
Active memory trace
assigned to the IMPlied
trace
CALCulate<Chn>:MATH[:EXPRession][:
DEFine]
MDATA1
MDATA2
MDATA3
MDATA4
MDATA5
MDATA6
MDATA7
MDATA8
Memory trace named Mem<n>
[Trc<m>]. The trace name is
unique because <n> counts
all data and memory traces in
the active setup.
TRACe:CLEar
TRACe:COPY
TRACe[:DATA]:STIMulus[:ALL]?
TRACe[:DATA][:RESPonse][:ALL]?
CALCulate<Chn>:MATH[:EXPRession][:
DEFine]
TRACe:COPY <MemTraceName>, <DataTraceName>
Copies a data trace to a memory trace. The trace to be copied can be specified by two
alternative methods:
●
As the active data trace of channels 1 to 4 (CH1DATA, CH2DATA, CH3DATA,
CH4DATA). If a mathematical trace is active, the associated data trace is copied.
●
As a trace with a name (string variable).
The created memory trace can be specified as follows:
●
As the memory trace named Mem<n>[Trc<m>], where n = 1, ... 8 and Trc<m> is
the name of the copied data trace (MDATA1, MDATA2, MDATA3, MDATA4,
MDATA5, MDATA6, MDATA7, MDATA8).
●
As a memory trace with an arbitrary name (string variable).
An existing memory trace with the same name is overwritten.
Note: The copied trace is the data trace which is not modified by any mathematical
operations. To copy a mathematical trace to a memory trace, use TRACe:COPY:MATH.
To copy the active trace to the memory using an automatic memory trace name, use
CALCulate<Chn>:MATH:MEMorize.
SCPI command reference
