R&S ZNB Series User Manual

Getting started
R&S
®
ZNB/ZNBT
53User Manual 1173.9163.02 ─ 62
Customizing the screen
The contents of the screen and the size and position of many display and control ele-
ments are not fixed. You can display or hide most elements. You can also drag and
drop traces, info fields, and even the softtool panel to your preferred position; see
Chapter 3.3.5.4, "Using drag and drop", on page 69.
For example, you can show/hide the on-screen hardkey panel by selecting/deselecting
"Display" > "View Bar" > "Hard Key Panel On" from the main menu.
Using (Virtual) Hardkeys
To access an instrument function:
1. Press a (virtual) key, e.g. the [Meas] key in the Trace section.
The corresponding softtool expands at the current docking position.
2. Activate the desired softtool tab, e.g. "Z←Sij".
Operating the instrument
