3. Select a control element, e.g. "Z←S11".
The diagram immediately reflects your selection. The active trace shows the mea-
surement results for the selected measured quantity.
A control element with three dots (e.g. System – [Setup] > "Setup" > "System Con-
fig...") opens a dialog, containing a group of related settings, a wizard or additional
information.
Using the menu bar
The menu bar at the bottom of the application screen provides alternative access to all
instrument functions. To repeat the measured quantity selection described above,
► Select Trace – [Meas] > "Z←Sij" > "Z←S11".
The diagram immediately reflects your selection. The active trace shows the mea-
surement results for the selected measured quantity. At the same time, the related
softtool tab is opened.
Using context menus
Context menus are another alternative for quick access to instrument settings.
1. Touch and hold (right-click) the measured quantity section in the trace info for a
couple of seconds until the context menu appears.
