Command reference

R&S

ZNB/ZNBT

845User Manual 1173.9163.02 ─ 62

CALCulate:CALValidate:CHARacteriza <String>

Selects the CalU characterization to be used for the cal validation.

Use CALCulate:CALValidate:STANdard to select the CalU standard to be used

for the validation.

Parameters:

<String> *RST: 'Factory'

Manual operation: See "Characterization" on page 510

CALCulate:CALValidate:RESPonse:MAGNitude:LOWer <Port>, <Value>

CALCulate:CALValidate:RESPonse:MAGNitude:UPPer <Port>, <Value>

Defines the maximum magnitude deviations from the reference characterization S-

parameters that are allowed during cal validation.

Use CALCulate:CALValidate:CHARacteriza to select the reference characteri-

zation.

Parameters:

<Port> Physical analyzer port no.

<Value> *RST: -0.2 (LOWer) | +0.2 (UPPer)

Default unit: dB

Manual operation: See "Validation Limits" on page 510

CALCulate:CALValidate:RESPonse:PHASe:LOWer <Port>, <Value>

CALCulate:CALValidate:RESPonse:PHASe:UPPer <Port>, <Value>

Defines the maximum phase deviations from the reference characterization S-parame-

ters that are allowed during cal validation.

Use CALCulate:CALValidate:CHARacteriza to select the reference characteri-

zation.

Parameters:

<Port>

<Value> *RST: -2 (LOWer) | +2 (UPPer)

Default unit: degrees

Manual operation: See "Validation Limits" on page 510

CALCulate:CALValidate:RUN

Runs the cal validation with its configured settings.

Usage:

Event

Manual operation: See "Validate" on page 509
