The equalizer can be enabled/disabled using CALCulate<Chn>:EYE:
EQUalization:STATe.
Suffix:
<Chn>
.
Channel number used to identify the active trace
<1|2>
Parameters:
<CTLE Poles> Default unit: Hz
Options: R&S ZNB/ZNBT-K20
Manual operation: See "CTLE Equalizer" on page 703
CALCulate<Chn>:EYE:EQUalization:CTLE:ZERO <CTLE Zero>
Specifies the zero of the equalizer (a two-pole filter with single zero) used at the
receiver simulation of the related eye diagram.
This command will raise an execution error if the active trace in the selected channel is
not an eye diagram.
The equalizer can be enabled/disabled using CALCulate<Chn>:EYE:
EQUalization:STATe.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<CTLE Zero> Default unit: Hz
Options: R&S ZNB/ZNBT-K20
Manual operation: See "CTLE Equalizer" on page 703
CALCulate<Chn>:EYE:EQUalization:STATe <Boolean>
Enables/disables the CTLE at the receiver simulation of the related eye diagram.
This command will raise an execution error if the active trace in the selected channel is
not an eye diagram.
The parameters of the equalizer (a two-pole filter with single zero) can be specified
using CALCulate<Chn>:EYE:EQUalization:CTLE:DC, CALCulate<Chn>:EYE:
EQUalization:CTLE:ZERO and CALCulate<Chn>:EYE:EQUalization:CTLE:
POLE<1|2>.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<Boolean> *RST: OFF
Options: R&S ZNB/ZNBT-K20
Manual operation: See "Active" on page 702
