R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
923User Manual 1173.9163.02 ─ 62
CALCulate<Chn>:LIMit:SEGMent<Seg>:TYPE................................................................. 937
CALCulate<Chn>:LIMit:SOUNd[:STATe]........................................................................... 938
CALCulate<Chn>:LIMit:STATe.........................................................................................938
CALCulate<Chn>:LIMit:STATe:AREA............................................................................... 939
CALCulate<Chn>:LIMit:TTLout<Pt>[:STATe]..................................................................... 939
CALCulate<Chn>:LIMit:CIRCle:CLEar
Resets the circle test for the active trace of channel <Chn>.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Usage: Event
Manual operation: See "Clear Test" on page 388
CALCulate<Chn>:LIMit:CIRCle:DATA <CenterX>, <CenterY>, <Radius>
Defines a circle limit lines by its center coordinates and its radius.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<CenterX> Range: Virtually no restriction for center coordinates.
*RST: 0
Default unit: NN
<CenterY> Range: Virtually no restriction for center coordinates.
*RST: 0
Default unit: NN
<Radius> Range: Virtually no restriction for radius (use positive val-
ues).
*RST: 1
Default unit: NN
Example: See CALCulate<Chn>:LIMit:CIRCle[:STATe]
Manual operation: See "Radius / Center X / Center Y" on page 389
CALCulate<Chn>:LIMit:CIRCle:DISPlay[:STATe] <Boolean>
Displays or hides the circle limit line associated to the active trace.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<Boolean> ON | OFF - Circle limit line on or off.
*RST: OFF
SCPI command reference
