Command reference
R&S
®
ZNB/ZNBT
945User Manual 1173.9163.02 ─ 62
SCPI GUI
POLar
COMPlex (for R&S ZVR compatibility)
"Real Imag"
GDELay "Delay"
REAL "Real"
IMAGinary "Imag"
SWR "SWR"
LINPhase
MLPhase (for R&S ZVR compatibility)
"Lin Mag Phas"e
LOGPhase
MDPhase (for R&S ZVR compatibility)
"dB Mag Phase"
IMPedance "R + j X" for reflection measurement traces
"R + j X series" for transmission measurement
traces
PIMPedance "R + j X", for reflection measurement traces
"R + j X parallel" for transmission measurement
traces
ADMittance "G + j B" for reflection measurement traces
"G + j B series" for transmission measurement
traces
PADMittance "G + j B" for reflection measurement traces
"G + j B parallel" for transmission measurement
traces
MIMPedance "Imp Mag" for reflection measurement traces
"Imp Mag series" for transmission measurement
traces
MPIMpedance "Imp Mag" for reflection measurement traces
"Imp Mag parallel" for transmission measurement
traces
MADMittance "Adm Mag" for reflection measurement traces
"Adm Mag series" for transmission measurement
traces
MPADmittance "Adm Mag" for reflection measurement traces
"Adm Mag parallel" for transmission measurement
traces
INDex Index
SCPI command reference
